Model:MSBNR
External turning toolholders(MSBNR)
Description
Type |
Stock |
Dimension(mm) |
Applicable Inserts |
Clamping screw |
Shim |
Wrench |
Clamp |
ClampingStud |
||||||
R L |
a |
b |
L |
h |
s |
e |
||||||||
MSBNR/L 2020K12 |
20 |
20 |
125 |
20 |
17 |
34 |
SN口口1204口口 |
WS06 1025 |
MS 1204 |
S3 |
MCL 1814 |
MSP617 |
||
MSBNR/L 2525M12 |
25 |
25 |
150 |
25 |
22 |
32 |
WS06 1030 |
|||||||
MSBNR/L 3232P12 |
32 |
25 |
170 |
32 |
22 |
32 |
||||||||
MSBNR/L 2525M15 |
25 |
25 |
150 |
25 |
22 |
38 |
SN口口1506口口 |
WS06 1030 |
MS 1504 |
S3 |
MCL 2114 |
MSP821 |
||
MSBNR/L 3232P15 |
32 |
32 |
170 |
32 |
29 |
38 |
||||||||
MSBNR/L 3232P19 |
32 |
32 |
170 |
32 |
27 |
45 |
SN口口1906口口 |
WS08 1038 |
MS 1904 |
S4 |
MCL 2117 |
MSP1021 |
||
MSBNR/L 4040R19 |
40 |
40 |
200 |
40 |
35 |
45 |
||||||||
MSBNR/L 4040S25 |
40 |
40 |
250 |
40 |
34 |
60 |
SN口口2509口口 |
WS10 1035 |
MS 2508 |
S4 S5 |
MCL 3220 |
MSP1229 |
||
